40KW Five Axis CNC Machining Center 2650×3320×3000mm HSK A63 Spindle Machining Center

Brand Name : Lishang Precision Machinery

Model Number : LS-U800

Certification : CE ISO

Place of Origin : Shenzhen China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100/month

Delivery Time : 15-30days

Packaging Details : durable case

Name : Five Axis CNC Machining Center

Table specifications (table diameter) : Ø800mm

Tilt (A-axis) and Rotary (C-axis) angles : A-axis: ±110°, C-axis: 360°

Tilt (A-axis) and Rotary (C-axis) speeds : A-axis: 80 rpm, C-axis: 120 rpm

Tilt (A-axis) and Rotary (C-axis) positioning accuracy : Tilt (A-axis) and Rotary (C-axis) positioning accuracy

Maximum table swing diameter (span) : 1000mm

Machine dimensions (L×W×H) : Approximately 2650×3320×3000mm

Machine weight : Approximately 9500kg

Total power requirements : 40KW

CNC system : Shanghai Renatron Bus absolute value control does not return to zero when powered on, and supports five-axis, five-link functionality.

Contact Now

Lishang LS-U800 Five-Axis CNC Machining Center With Renatron N5EC System, HSK A63 Spindle and Large Mold Equipment

Product description

The Lishang LS-U800 is a five-axis CNC machining center specifically designed for machining ultra-large, heavy, and complex parts, manufacturing giant molds, and precision cutting of heavy-duty aerospace/automotive structural components. Leveraging China's expertise in professional CNC machine tool R&D and manufacturing, its core features include an 850kg ultra-heavy-duty load capacity, an 800×1010mm ultra-large machining stroke, and micron-level precision control. It completely solves the pain points of traditional machine tools, such as insufficient load capacity, limited stroke, and large clamping errors in multi-process machining, making it suitable for the integrated machining needs of heavy-duty workpieces in high-end manufacturing.

The machine tool is equipped with the Shanghai Rinaker N5EC bus absolute CNC system, supporting five-axis five-linkage functionality without requiring zeroing upon startup, significantly reducing startup preparation time. Its core configuration includes an Ø800mm high-precision worktable, and the 850kg ultra-heavy load capacity can stably support giant molds, heavy aerospace structural components, and other workpieces. It enables complex curved surfaces and multi-faceted heavy workpieces to complete milling, drilling, and boring operations in a single setup, reducing clamping errors by more than 80% and significantly shortening labor costs.

Product specification

LS-U800 Specifications
Table specifications (table diameter) Ø800mm
Tilt (A-axis) and Rotary (C-axis) angles A-axis: ±110°, C-axis: 360°
Tilt (A-axis) and Rotary (C-axis) speeds A-axis: 80 rpm, C-axis: 120 rpm
Tilt (A-axis) and Rotary (C-axis) positioning accuracy A-axis: ±8", C-axis: ±5" (arc-seconds)
Tilt (A-axis) and Rotary (C-axis) repeatability A-axis: 5", C-axis: 5" (arc-seconds)
Maximum table swing diameter (span) 1000mm
X, Y, and Z axis travel 800*1010+230 (tool change stroke)*600mm
Maximum table load 850kg
Distance from spindle center to column guideway ---mm
Distance from spindle end to table surface 120-720mm
X, Y, and Z cutting feeds 1-10000mm/min
X, Y, and Z axis rapid feed rates 24, 24, 24m/min
Spindle speed range 50-16000rpm
Spindle taper HSK A63
X, Y, and Z axis ball screw specifications X:4012, Y:4012, Z:4012
X, Y, and Z axis rail specifications Roller: X:45, Y:45, Z:45 (6 slides)
Spindle motor Built-in (11- 15KW)
X, Y servo motor Straight Shaft (4KW)
Z servo motor Straight Shaft (4KW with Brake)
Positioning accuracy ±0.005mm
Repeatability ±0.003mm
Minimum travel unit 0.001mm
Machine dimensions (L×W×H) Approximately 2650×3320×3000mm
Machine weight Approximately 9500kg
Total power requirements 40KW
Cooling water capacity 160L
Used source air pressure 0.6-0.7mpa
Spindle HSK A63 built-in Speed ​​16000rpm

CNC system

Shanghai Renatron

Bus absolute value control does not return to zero when powered on, and supports five-axis, five-link functionality.

Number Items Quantity Manufacturer Name
1 Resin sand casting bed 1 set Yunnan Taibiao
2 Sheet metal main cover (front water tank) 1 set Dongguan Lishang
3 Fully sealed telescopic sheet metal 1 set Dongguan Lishang
4 Control system N5EC 1 set Shanghai Lynuc
5 Spindle servo motor 1 set Beijing Super Synchronous (CTB)
6 Spindle drive 1 set Beijing Super Synchronous (CTB)
7 X, Y, Z axis servo drive 1 set YASKAWA (Japan)
8 X, Y, Z axis servo motors 1 set YASKAWA (Japan)
9 A and C axis servo drive 1 set Thinkvo (Nanjing)
10 A and C axis servo motors 1 set DD Motor
11 X, Y, Z axis ball screws 1 set Taiwan Hiwin/Yintai/EvoVox/Kate/THK
12 X, Y, Y axis roller guides, Z axis roller guides 1 set Taiwan Hiwin/Yintai/FZS/Kate/THK
13 HSKA63 spindle (Ø190, 16,000 rpm) with built-in speed 1 set Luo Yi/Jianchun/NTU/Yucheng/Luo Da/LFP
14 Tool cylinder (direct spindle with booster cylinder) 1 set Zhongri (Hao Xiao)/Gao Hong
15 HSK A63-24T tool changer with arm 1 set Taiwan/Deshi/Desu/Okada/Gutian
16 Spindle oil cooler 1 set Reid/Qianguan/Reco/Hart
17 Heat exchanger/air conditioner 1 set Reid/Qianguan/Reco/Hart
18 Main electrical components 1 set Schneider (France)
19 Pneumatic kit, solenoid valve 1 set Taiwan Goldware
20 Positive displacement oiler 1 set Taiwan Yuxiang
21 Complete set of high-pressure flushing guns 1 set Beize Hardware
22 Complete set of air guns 1 set Beize Hardware
23 Dual filter separators 1 set Beize Hardware (Taiwan Goldware)
24 Dual air-oil separators 1 set Beize Hardware (Taiwan Goldware)
25 Tool magazine air tank 1 set Beize Hardware
26 LED work light 2 sets Shenzhen Oujie/MyWorld
27 Tri-color LED light 1 set Shenzhen Oujie/MyWorld
28 Cooling pump system 1 set Dongguan Heyi/Jiahe
29 Flushing system 1 set Dongguan Heyi/Jiahe
30 Chain chip removal system 1 set Dongguan Lishang

Product Feature

1. Five-axis linkage + intelligent CNC for increased efficiency in complex machining

2. Ultra-heavy payload + ultra-long travel for machining large workpieces

3. Micron-level high-precision configuration for more reliable machining quality

4. Globally high-quality support for maximum stability and durability

5. Comprehensive auxiliary systems for enhanced machining convenience

List of tool

Number Name Specifications or markings Quantity Notes
1 Leveling shim X pcs Adjusting the foundation
2 Leveling bolt X pcs Adjusting the foundation
3 Toolbox and tools 1 set
4 Network cable 1 strip
5 Operating instructions 1 set
6 Memory card 1 pc
